NAD’s affordable CS1 Endpoint Network Streamer lets you add music streaming capability to any stereo or home-theatre system. Or you can configure a low-footprint music system for your den or home office by connecting the CS1 to a pair of powered speakers. The CS1 supports the most popular network streaming and casting protocols, including Apple AirPlay 2, Chromecast, Spotify Connect, Tidal Connect, DLNA mobile and computer apps*, and Roon, so you can control playback with the music apps you use every day. The CS1 employs audiophile-grade components and can play high-resolution audio, up to 24-bit/192kHz.

AUDIO

THD + N (20 Hz – 20 kHz)

<0.03% 20-20 kHz -1dBFS output

Signal-to-Noise ratio

-94dB (ref 2V)

Frequency response

20-20 kHz +/-0.3dB; 50 kHz -3dB

Native sampling rate

Up to 192 kHz

Bit depth

16-24

Supported audio file format

LPCM, MP3, AC3, Ogg Vorbis, HE-AAC, MQA & WMA decode capability

Supported 3rd party service provider

Spotify Connect, Tidal Connect, Apple AirPlay 2, Google Chromecast, DLNA, Roon

DAC

TI PCM5142

Processor

ARM® Cortex™ -A53, Quad-Core, 1.5GHz per core

CONNECTIONS

Power

AC adapter

Input: 100-240V AC 0.3A

Output: 5V DC 1A

Network connectivity

Ethernet RJ45 100 Mbps

Wi-Fi 5 (802.11ac 2.4GHz/5 GHz)

DLNA/UPnp*

Bluetooth

Bluetooth 5.2

BT Profiles: A2DP 1.2, AVRCP 1.3, SPP, HFP, HSP, HOGP

NFC

NFC for easy Bluetooth connection

12V Trigger Out

3.5mm Mini-jack x 1

Analog Out

RCA x 1

Coaxial Out

RCA 75 ohms

Optical Out

TOSLINK x 1

USB IN

USB C for AC adapter

* Certification in progress as of publishing date

GENERAL

Status Indicator

Front Panel LED

Function Button

Front Panel Function Button

Power Consumption

0.5W Network Standby

Finish

Black

DIMENSION AND WEIGHT

Gross dimensions (W x H x D)**

140 x 140 x 55 mm (5 1/2 x 5 1/2 x 2 1/16 inches)

Net Weight

1.5 kgs / 3.3 lbs

Shipping Weight

1.7 kgs / 3.8 lbs
