NAD T778 namų kino stiprintuvas

NAD’s reference Audio Video Receiver (AVR) is a cutting-edge powerhouse for state of the art music and home theater. Well known for our high value/ high performance reputation in the AVR category, the brand’s reference model builds on that legacy with an expansion of unwavering philosophy of real-world performance, simplicity of operation, and future upgradeability.

FTC8 Ohms140W (21.5dBW)4 Ohms170W (22.3dBW)Full Disclosure Power (all channels driven simultaneously at full bandwidth at rated distortion)9 x 85WIHF Dynamic Power8 Ohms165W (22.2dBW)4 Ohms280W (24.5dBW)Total harmonic distortion at rated power<0.08%IM distortion at 1/3 rated power<0.03%Damping factor>300 (20Hz-1kHz, 8 ohms)Input sensitivity and impedance1.12Vrms (ref. 8 Ohms, VOL at 0dB)Frequency response+0.3/-0.8dB (ref. 1kHz, 20Hz-20kHz)Signal/noise ratio>100dB (ref. rated power at 8 Ohms, A-Weighted)Signal/noise ratio>85dB (ref. 1W at 8 Ohms, A-Weighted)

Preamplifier

LINE INPUTFrequency response±0.3dB (ref. 20Hz – 20kHz)Signal-to-noise ratio>100dB (ref. 2V, A-Weighted)Total harmonic distortion<0.01%Input sensitivity245mVrms (ref. 2V)Maximum output level>4.5VrmsPHONO INPUTInput Sensitivity6.2mVrms (ref. 2V)(ref. 20Hz – 20kHz)Signal-to-noise ratio>80dB (ref. 2V, A-Weighted)Maximum Input Level>90mVrms (1kHz)

Power Consumption

Standby power<0.5W (full standby)<8W (network standby)

Dimension and Weight

Unit Dimensions (W x H x D)435 x 140 x 430mm (Gross)* 17 3/16 x 5 9/16 x 16 15/16?**Net Weight12.1kg (26.7lb)Shipping Weight15.5kg (34.2lb)
